M9540 Belly Skid Plate/Brush Guard

   / M9540 Belly Skid Plate/Brush Guard #1

ovrszd

Epic Contributor
Joined
May 27, 2006
Messages
31,317
Location
Missouri
Tractor
Kubota M9540, Ford 3910FWD, Ford 555A, JD2210
My new tractor has spent the first three months of it's life in the brush. I consider myself cautious about getting brush under the tractor but it still happens. One time my grapple wouldn't grip. I found the connection to the solenoid on the valve had came undone from brush. The recent cold spell brought me into the shop for a few days. I was rolling around under the tractor on a creeper making sure everything was intact when I saw this.











Those are the transmission/hydraulic filters. Kinda freaked me out so I decided to build a skid plate. There are several drilled and threaded holes on the bottom of the transmission and rear axle assembly to use for bracketry. I built a basic angle iron frame using six of those. Then skinned it with 1/8" sheet metal. Then I used expanded metal to make a side shield that would allow me to see the transmission controls, hydraulic valves and transmission filters. Also thought it would make it easier to clean out if needed. The side shield is held in place with four 5/16" bolts coming up from the bottom. I welded the nuts to the shield brackets so a second wrench isn't needed to install or remove. Here's the skid and side shield uninstalled.











I tried to take "like" pictures without the skid installed and then with it installed. I'll post them in pairs to illustrate what's accomplished with the plate.

First two pictures are taken toward the back of the tractor from under the front axle.







These two are taken toward the front of the tractor from under the rear axle.







These two are showing the right sider undercarriage where all the hydraulics and filters are.







Here are pics taken from the right side of the tractor toward the filters.







To service the filters or adjust the shifting linkages the side shield is removed by taking out the four 5/16" bolts.







These two show how the plate is bolted to the tractor. In the first picture the four orange colored bolts and the one bigger silver bolt hold from underneath. The second pic show a bolt just behind the filters going into the axle housing.







I also put two bolts thru the factory hydraulic shield thru my skid plate to tie all that together and give the factory shield more strength. They are the two 5/16" bolts farthest from the camera.





All in all I think I've protected everything pretty well. Not going to say it can't be infiltrated but I'd say my chances of damage are a LOT less. Here's a couple more random pics for clarity.









Here's a couple from a bit more distance to show what it looks like installed.




   / M9540 Belly Skid Plate/Brush Guard #2

CCOUGHRAN1

Silver Member
Joined
Jun 22, 2006
Messages
193
Yesterday I was just at my local Kubota dealer inquiring about this exact modification. I was hoping that Kubota has something they offered as an accessory. I was told of a couple mowing contractors that build their own skid plates.

I am very impressed with how your modification looks. Might have to copy it an build my own...

   / M9540 Belly Skid Plate/Brush Guard
  • Thread Starter
#3
OP
ovrszd

ovrszd

Epic Contributor
Joined
May 27, 2006
Messages
31,317
Location
Missouri
Tractor
Kubota M9540, Ford 3910FWD, Ford 555A, JD2210
Yesterday I was just at my local Kubota dealer inquiring about this exact modification. I was hoping that Kubota has something they offered as an accessory. I was told of a couple mowing contractors that build their own skid plates.

I am very impressed with how your modification looks. Might have to copy it an build my own...


Thank you for the compliment. Copy away, that's why I posted it. You might even see things you could do to improve it. If so the only price is that you post them. :thumbsup:

   / M9540 Belly Skid Plate/Brush Guard #4

RFB

Platinum Member
Joined
Jan 21, 2006
Messages
963
Location
West Central Idaho
Tractor
Kubota L5740HSTC3; B3000HSDCC
Very nice work sir!

   / M9540 Belly Skid Plate/Brush Guard #5

DT86

Elite Member
Joined
Dec 19, 2010
Messages
4,017
Location
VA
Tractor
Kubota
Very nice.

   / M9540 Belly Skid Plate/Brush Guard #6

TripleR

Super Star Member
Joined
Mar 5, 2009
Messages
18,615
Location
Missouri
Tractor
Kubota M8540HDC, L5740HSTC, BX2200, BX2660, John Deere 425&1025R, Case, Massey Ferguson, Ford
Very, nice, I am surprised no one is marketing something like that, I would sure buy one.

Last edited:
   / M9540 Belly Skid Plate/Brush Guard #7

DT86

Elite Member
Joined
Dec 19, 2010
Messages
4,017
Location
VA
Tractor
Kubota
TripleR said:
Very, nice, I am surprised no one is marketing something like that, I's sure buy one.

Me too.

   / M9540 Belly Skid Plate/Brush Guard #9

dbaer78

Gold Member
Joined
Apr 30, 2012
Messages
391
Location
nashville,indiana
Tractor
kubota mx5100hst
Very sharp work. I plan on welding up something very similar for my mx5100 this winter when the weather gets to nasty for log skidding.

   / M9540 Belly Skid Plate/Brush Guard #10

Rustyiron

Super Member
Joined
Mar 5, 2011
Messages
5,471
Location
Lakes Region, Maine
Tractor
M 9540 Kubota
Very nice! This is on my "winter list" to do. I plan on guarding the oil pan as well and incorporate a grill and side panel protection as well. Would you be able to save me some leg work and tell me what size(s) bolts go into those transmission holes in a 9540? It looks like there are 2 sizes, I assume metric. Working in the woods is hard on equipment! Thanks, and very nice work!
