GC2300 FEL hydraulics question

[buckwheat]

So I was installing a Woods BH6000 backhoe and everything was going well until I got to the hydraulics. Woods gives very explicit instructions if I have a Woods FEL, but for the Massey loader they simply tell me to tap into the PBY line.

I cannot figure out which valve is the PBY on the FEL. I have a T2, T3, and P2 port. I think the T2 is the return, I'm suspecting that P2 is the pressure hose, and that would maybe make T3 the PBY, but I'm not really certain.

Nimco makes the control valve, but their website is of no use. I suspect I have a CV112 control valve, but there are no schematics.

Does anyone know which port is which on the 2350 loader?



[Aguanga]

Does anyone know which port is which on the 2350 loader?

I'm going to need the same info to set up rear remotes for a TNT addition to my 2300... Maybe someone out there is familiar. How are the 2310's plumbed? Are the backhoe hydraulics run off of the loader valve's power beyond port?



[kennyd]

How many hoses total do you have connected to the valve now?



[buckwheat]

I have three lines running to the controls from the tractor. The loader owner's manual/assembly instructions only indicate two lines (pressure and return) to be run to the controls. The third line comes off the right side of the controls with a 90 elbow on it, but does not show up in the loader manual. I am assuming that this is the power beyond.

My backhoe subframe kit came shorted on one hose which I am waiting for, so I haven't tried this hydraulic arrangement out yet.



[kennyd]

Well, with 3 hoses connected, you definitly have PowerBeyond. Not sure of your markings though, the PB port is usualy marked with a "B"

Any chance of you posting a picture?



[buckwheat]

This is a photo as seen from the operator's seat. There are no PB stampings. CW from the top left they are P3 P2 , T3A, T2B. The bottom left has no markings.



[kennyd]

HHHMMMM....You will have to trace the lines then. One should come from the pump, one should go directly to the tank, and the last one should feed the 3PH-that's the one that should be the PB line. By looking at the picture I "think" it will be the line on the far right coming out of the side of the valve.
