JDQA dimensions?

[larboc]

Anyone have the drawings for the JDQA system? Namely center-center hook distance. I measure it being approximate 40.25" but it would nice to know for sure instead of being at one extreme of clearance.



[Wagtail]

That sounds about right.

I just went out and measured my 300CX, I went between the outside edges of the hooks of the implement attached, and that was 43 1/4".
The hooks were 3" wide... so that would make it 40 1/8".

I did measure twice to be sure.



[mike48130]

Here is a drawing of mine I measured years ago thinking I would make some attachments, but never did. The hooks and pins you can but from JD dealers so you don't have to make those if you want.



[larboc]

Seems like the kind of thing that deere would have 1) Made all dimensions exactly to the nearest half inch and 2) Published. Thanks mama deere.
Thanks for the prints, I ended up making multiple trips through the snow from the shop to the barn with a tape measure and go it figured out.
I'm a little skeptical of your width, that puts the center to center distance at 40.05" which I think is too narrow. The 15" dimension is a little shorter than I remember and I was using deere weld on brackets. I had 15 1/16th from the top to the center of the pin.



[beenthere]

larboc
What is in the barn that you are measuring? suspecting it is a 420 or 430 FEL. or is it something else?



[larboc]

larboc
What is in the barn that you are measuring? suspecting it is a 420 or 430 FEL. or is it something else?

430 FEL



[mike48130]

View attachment 533667View attachment 533668I don't recall how I measured them many years ago. But I just checked my widths today, and it is just under the 43.5" for the overall. I suspect I measured it with the bucket off the first time, and probably picked up the widest points. Bucket is on now, and didn't take it off. This is on a 300CX with light duty bucket. My overall is just a hair under 43.5" from outside to outside, but might be a bit different with the bucket off and measuring from a more solid spot on the brackets. That puts the inside dimension at about 36.5", and center to center at around 40".

See pictures for measurements.



[beenthere]

Seems like the kind of thing that deere would have 1) Made all dimensions exactly to the nearest half inch and 2) Published. Thanks mama deere.
.....................

Prolly is really in metric, so center to center maybe 102 cm.
But as long as you have the FEL that you want to fit up to, then actual measurements of the FEL should work for your attachments.
What attachments are you fabricating ??



[larboc]

View attachment 533667View attachment 533668I don't recall how I measured them many years ago. But I just checked my widths today, and it is just under the 43.5" for the overall. I suspect I measured it with the bucket off the first time, and probably picked up the widest points. Bucket is on now, and didn't take it off. This is on a 300CX with light duty bucket. My overall is just a hair under 43.5" from outside to outside, but might be a bit different with the bucket off and measuring from a more solid spot on the brackets. That puts the inside dimension at about 36.5", and center to center at around 40".

See pictures for measurements.

Interesting. 40" even would make sense to me but there doesn't seem to be 1/4" worth of play. When I find my original bucket (under 100" of snow now, somewhere in "implement row") I'll get some precise measurements and see what I have.



[larboc]

Prolly is really in metric, so center to center maybe 102 cm.
But as long as you have the FEL that you want to fit up to, then actual measurements of the FEL should work for your attachments.
What attachments are you fabricating ??

Made pallet forks, adapted a 7.5 box blade, working on making a post hole digger.
