Here is the current progress of my Power Rake that I'm building for my Kubota BX.
I didn't want to start this thread right when I started as I usually get partway into a project and it ends up never getting finished but this one has come a long ways.
Rake is going to be about 58 wide (roller width), utilizing a 1:1 gear box with 20T and 10T sprockets to cut the RPMs in half.
Also be aware that this will be a light use implement so I tried keeping cost down.
All hardware was bought from Surplus Center and steel from local steel supplier.
Here is my first real use with a plasma cutter. First one came out pretty good but had a lot of problems getting the others to cut well. I'm sure it was my mistake.



Also bought some nice Hougen Rotacut hole cutters to cut out the 1-1/4" & 1" holes.



Getting the plates tacked in place.



Shaft and plates all welded in, no changing it now.




Building the frame.



Opps! :duh: Broke one of the cutters. Hougen was nice enough to send me a replacement.



Father in-law had some scrap C-channel that was perfect, just had to weld two pieces together.



Still need to build an idle gear tensioner.



Break time to think about the swivel hinge design.



Still trying to keep price down, I came up with idea to use some stock 3pt parts from Farm & Fleet. I used 2 (actually 3) top link bushings and a top link pin to create the swivel joint.
I took two bushings and put them through the tubing, welded and ground flush.




Here is what the tube with bushing looked like with put between the support plates. You can see the recess which is where the extra bushing will go. What this does is allow me to remove the tubing from the main frame if I ever need to.



And here is the 3rd bushing cut down and in place ready to be welded. And the bottom of the pin which just uses a pin to hold it.




What it looks like so far.



Hopefully start working on the 3pt hookup and also need to build the gauge wheels. Then the fun come from cutting and welding on all the teeth. :eek:

   #2

Scooby074

Super Member
Joined
Aug 4, 2006
Messages
6,364
Location
Nova Scotia
Tractor
BX 25, ZD 326
Subscribed.

An interesting project and something I considered myself.

   #4

rswyan

Super Member
Joined
May 12, 2004
Messages
7,557
Location
Northeast Ohio
Tractor
Kubota B2910, Simplicity 18 CFC, Cub Cadet 782
Cool project ... looking great so far ... nice job :thumbsup:

   #5

GolfAddict

Veteran Member
Joined
Oct 19, 2011
Messages
2,383
Location
SE Minnesota
Tractor
Kubota BX24; John Deere 4020
Well, you have an audience now. Have to finish this one or you'll leave us all hanging!

Fascinating project :thumbsup::thumbsup:

   #6

Xfaxman

Super Star Member
Joined
Feb 8, 2013
Messages
10,892
Location
Guthrie, OK
Tractor
Toolcat 5610 G Bobcat V417 TORO+Loader
Me is watching too. :thumbsup:


  • Thread Starter
#7
OP
Z

Zick

Platinum Member
Joined
Sep 7, 2007
Messages
835
Location
WI
Tractor
BX 2350
Well, you have an audience now. Have to finish this one or you'll leave us all hanging!

Fascinating project :thumbsup::thumbsup:

Oh this one will get done, I'm too far in to quit now. But it may take a little while still.
I'll update as I move along.

:drink:

   #8

pmsmechanic

Elite Member
Joined
Dec 6, 2013
Messages
3,404
Location
Southern Alberta, Canada
Tractor
4410 and F-935 John Deere, MF 245
I want to see this through to the end! Looks interesting. I need to make something like this to level off my lawns.


  • Thread Starter
#10
OP
Z

Zick

Platinum Member
Joined
Sep 7, 2007
Messages
835
Location
WI
Tractor
BX 2350
Got a little more done.













Left the top bracket extra large in case I decide to add in the long open hole slot like other Harley rake have. Not sure I really need it or not. Basically like this.


Top
