Reassembling starter, brushes

   / Reassembling starter, brushes #1

MMagis

Veteran Member
Joined
Aug 12, 2005
Messages
1,491
Location
Guernsey Co. Ohio
Tractor
Ford 3000, JD 2550
I was installing a new drive on the starter for my Ford 3000 last night and accidently let the rotor pull out from the brushes. It was late so I didn't spend much time on it yet, but was having trouble figuring out how to hold the brushes out to get the rotor back in position. I tried removing the springs, and got one back together, but I don't think that's going to work for all four. Anyone know of any tricks? I didn't notice any holes to stick a pin through. I might be able to find something to hold the springs back, but I don't know what it would be, or how that would work just yet. Figured I'd ask before diving back into it tonight.
Thanks

   / Reassembling starter, brushes #2

davesl708

Elite Member
Joined
Dec 13, 2014
Messages
3,500
Location
Shawnee, KS, USA
Tractor
Kubota BX2200D,
I am not familiar with your starter. On the ones I have worked on I had access to the brushes from the rear and slid the rotor in then with a wooden stick from a fudge bar (repurposed) held each one back an walked the rotor in.
Hope this helps.

   / Reassembling starter, brushes
  • Thread Starter
#3
OP
M

MMagis

Veteran Member
Joined
Aug 12, 2005
Messages
1,491
Location
Guernsey Co. Ohio
Tractor
Ford 3000, JD 2550
Thanks. I forgot to mention that there’s only about ½” opening between the end plate and canister to access the bushes. Not a lot to work with, but that gives me some ideas.

   / Reassembling starter, brushes #4

JRobyn

Elite Member
Joined
Dec 4, 2003
Messages
2,794
Location
Middle TN
Tractor
Kubota L4330HST
I have sometimes had success with very thin, solid wire, like florist's wire, to tie them back with a loop of the wire, and then when almost fully assembled, cut and remove each loop.

   / Reassembling starter, brushes #5

ruffdog

Super Member
Joined
Dec 31, 2011
Messages
8,190
Location
southern wisconsin
Tractor
Bobcat Toolcat 5610G, Deere X744, Cub Cadet IH 982
Some starters have a hole through the brush cage that allows a wire (like a straightened paper clip) to keep the brush back until the armature is in place. After it is together, just pull the wires out.

   / Reassembling starter, brushes #6

Winmac

Gold Member
Joined
Dec 31, 2011
Messages
367
Tractor
Landini 6860
What style springs, are they coil wound flat spring type?
I've had good luck with this method, pull the spring to the side, slide the brush back far enough to let the spring rest against it. Once you have all 4 done and the brush holder back on the commutator, working thru the 1/2 gap use a o-ring pick to pull back the spring and screw driver to push the brush in place. You may need A second set of hands to hold everything in place.

   / Reassembling starter, brushes #7

Texasmark

Elite Member
Joined
Apr 24, 2012
Messages
3,466
Location
N. Texas
Tractor
Ford: '88 3910 Series II, '65 3000; '07 6530C Branson with FEL, 2020 LS MT225S. All Diesels
I have done the above or on some where there's access, used the brushes braded cable and a pair of long nose pliers to pull on the brushes while pushing on the armature, alternating back and forth, side to side till it gets in. Works a lot better with another set of hands or a couple of long nose vise grips.

   / Reassembling starter, brushes #8

PILOON

Super Star Member
Joined
Aug 26, 2004
Messages
10,908
Location
North of Mtl,Que,Can (Ste Adele)
Tractor
MT180D
On some I use string to tie back, others bent wire and then some simply move the spring off to the side.

An old trick when installing new brushes is to rub chalk on the commutator to seat the brushes in.

   / Reassembling starter, brushes
  • Thread Starter
#9
OP
M

MMagis

Veteran Member
Joined
Aug 12, 2005
Messages
1,491
Location
Guernsey Co. Ohio
Tractor
Ford 3000, JD 2550
I appreciate all the tips. I was able to move a couple so the spring end was sitting on the square frame the brushes sit in, and the other two I slipped a piece of toothpick under. It went smoother than I expected. Thanks again

   / Reassembling starter, brushes #10

Gary Fowler

Super Star Member
Joined
Jun 23, 2008
Messages
11,998
Location
Bismarck Arkansas
Tractor
2009 Kubota RTV 900, 2009 Kubota B26 TLB & 2010 model LS P7010
I have heard about folks freezing the brushes in place with a few drops of water then installing them. Ice melts and all is good.
