XR4100 series hydraulic top link?

   #1

dstriplett

Member
Joined
Aug 27, 2016
Messages
42
Location
NC
Tractor
LS XR4145
Any on you guys replaced the mechanical top link with hydraulic top link? Do you happen to recall the setup specs? Hoses/couplings/cylinder specs etc? Finding technical info for LS tractors is way more difficult than it should be in my opinion -- especially when your local dealer goes belly up.

   #2

MtnViewRanch

Elite Member, Advertiser
Joined
Mar 19, 2005
Messages
10,258
Location
4000\' mountains of Southern California
Tractor
Mahindra 7520, Mahindra 3215HST, Case 580 extendahoe, Case 310 dozer, Parsons trencher, Cat D6,
I provide a 2 1/2" dia cylinder with a 1 1/2" dia rod. Working lengths can be cat 1 @ 17"-23" or cat 1-2 at 19"-27" for the 55hp unit. Hose kit has 30" & 36" hoses with 1/2" male AG type couplers. A set of flow restrictors to make adjustments slower and smoother.

Find something close to that and you should be all set.

Now I did just come across an odd requirement, but something was different with his draft links for some reason. :confused:

   #3

sodamo

Super Star Member
Joined
May 20, 2004
Messages
14,557
Location
Big Island, HI
Tractor
LS XR4140H (Mine) BX2380 (wife’s)
I replaced mine with same system I got from Brian years ago for my Kioti. Works very well.

   #4

lostcreekranch

Super Member
Joined
Dec 14, 2012
Messages
7,707
Location
Colorado County, Texas
Tractor
NH TL-100A with Bush Hog 5045 FEL, WR Long 3rd function, LS XR4155HC w/FEL, WR Long 3rd Function.
+1 for Fit-Rite.

Brian .. not only builds them .. he uses them!

   #5

XR4140

Bronze Member
Joined
Aug 24, 2018
Messages
55
Location
MO
Tractor
18 LS XR4140
I too was trying to save money on mine. This is what I have used pretty hard for 500 hours, works great for me.

All from agrisupply

90599 TOP LINK CYL CAT 1, 20-28" 1
18653 3/4"ADJ. ORB X 1/2"FEM. PT hyd fitting x 2
86668 1/2" X 24" HYDRAULIC HOSE x 2
86641 1/2-14 NPTF QUICK COUPLER W/BALL VALVE MALE 8GPM x 2

It was $215 shipped for me and have been worth every penny.

Hydraulic side link is from "CWA" on amazon. This is the description:
2 1/2" Bore x 4" Stroke x 1 1/2" Rod, 3000 PSI, SAE 8 Port Weld Clevis Cylinder

I did have to cut one side off the cylinder and one side off my factory side link and weld them together. But for less than $100 it was a no brainer. This setup has held up for me. YMMV.

   #6

hammick

Silver Member
Joined
Apr 27, 2016
Messages
158
Location
Montana
Tractor
LS MT357HC
I too was trying to save money on mine. This is what I have used pretty hard for 500 hours, works great for me.

All from agrisupply

90599 TOP LINK CYL CAT 1, 20-28" 1
18653 3/4"ADJ. ORB X 1/2"FEM. PT hyd fitting x 2
86668 1/2" X 24" HYDRAULIC HOSE x 2
86641 1/2-14 NPTF QUICK COUPLER W/BALL VALVE MALE 8GPM x 2

It was $215 shipped for me and have been worth every penny.

Hydraulic side link is from "CWA" on amazon. This is the description:
2 1/2" Bore x 4" Stroke x 1 1/2" Rod, 3000 PSI, SAE 8 Port Weld Clevis Cylinder

I did have to cut one side off the cylinder and one side off my factory side link and weld them together. But for less than $100 it was a no brainer. This setup has held up for me. YMMV.

How does your setup work without the flow restrictors Brian recommends?

   #7

XR4140

Bronze Member
Joined
Aug 24, 2018
Messages
55
Location
MO
Tractor
18 LS XR4140
How does your setup work without the flow restrictors Brian recommends?

Never knew anything about it. "make adjustments slower and smoother" I can live without that for the kind of money im saving (or potentially add it for cheap?)


  • Thread Starter
#9
OP
D

dstriplett

Member
Joined
Aug 27, 2016
Messages
42
Location
NC
Tractor
LS XR4145
Thanks for all of the replies folks. Very useful info.
